Fuse 800VAC gG 16A 22x65mm
920.752.40
| Series name | X800 | Power loss (W) | 2,2 |
| Rated current In (A) | 16 | Class | gG |
| Rated Voltage Un AC (V) | 800 | Rated breaking capacity I1 AC (kA) | 80 |
| Fuse Dimension (mm) | 22x65 | Fuse Connection/Terminal type | Cylindrical |
| Melting I²t value (A²s) | 380 | Total clearing I²t @Un AC (A²s) | 4180 |
| Applicable standards | IEC |
