Fuse 1000VDC aBat 1500A 103x106mm 4x M10 flush end terminals

Fuse 1000VDC aBat 1500A 103x106mm 4x M10 flush end terminals

536.862.15
Technical Properties
Series name B400 Power loss (W) 275
Rated current In (A) 1500 Class aBat
Fuse Dimension (mm) 103x106 Rated Voltage Un DC (V) 1000
Rated breaking capacity I1 DC (kA) 100 Time costant L/R (ms) 2
Fuse Connection/Terminal type Screw fixing Melting I²t value (A²s) 731600
Fixing dimensions M10 Total clearing I²t @Un DC (A²s) 2195000
Minimum breaking current (A) 15000 Applicable standards IEC
