Fuse 1000VDC EV-Full Range 60A 22x65mm
745.686.61
| Series name | EV65.1000 | Power loss (W) | 12 |
| Rated current In (A) | 60 | Class | EV Fuse – Full range |
| Fuse Dimension (mm) | 22x65 | Rated Voltage Un DC (V) | 1000 |
| Rated breaking capacity I1 DC (kA) | 25 | Time costant L/R (ms) | 2,5 |
| Fuse Connection/Terminal type | Cylindrical | Melting I²t value (A²s) | 1220 |
| Total clearing I²t @Un DC (A²s) | 4100 | Applicable standards | UL |
