Fuse 1000VDC EV-Full Range 70A 22x65mm
754.158.47
| Series name | EV65.1000 | Power loss (W) | 13 |
| Rated current In (A) | 70 | Class | EV Fuse – Full range |
| Fuse Dimension (mm) | 22x65 | Rated Voltage Un DC (V) | 1000 |
| Rated breaking capacity I1 DC (kA) | 25 | Time costant L/R (ms) | 2,5 |
| Fuse Connection/Terminal type | Cylindrical | Melting I²t value (A²s) | 2010 |
| Total clearing I²t @Un DC (A²s) | 6050 | Applicable standards | UL |
