Fuse 1500VDC aBat 160A 50x140mm M8 flush end terminals
744.821.60
| Series name | BPF1 | Power loss (W) | 34 |
| Rated current In (A) | 160 | Class | aBat |
| Fuse Dimension (mm) | 50x140 | Rated Voltage Un DC (V) | 1500 |
| Rated breaking capacity I1 DC (kA) | 100 | Time costant L/R (ms) | 3 |
| Fuse Connection/Terminal type | Screw fixing | Melting I²t value (A²s) | 6650 |
| Fixing dimensions | M8 | Total clearing I²t @Un DC (A²s) | 23300 |
| Minimum breaking current (A) | 1600 | Applicable standards | IEC |
Accessories
Available
