Fuse 1500VDC aBat 630A 103x144mm 4x M10 flush end terminals and microswitch adapter
842.982.93
| Series name | B500 | Power loss (W) | 170 |
| Rated current In (A) | 630 | Class | aBat |
| Fuse Dimension (mm) | 103x144 | Rated Voltage Un DC (V) | 1500 |
| Rated breaking capacity I1 DC (kA) | 250 | Fuse Connection/Terminal type | Screw fixing |
| Melting I²t value (A²s) | 145000 | Fixing dimensions | M10 |
| Total clearing I²t @Un DC (A²s) | 772800 | Minimum breaking current (A) | 6900 |
| Applicable standards | IEC |
