Fuse 1500VDC aBat 750A 103x144mm 4x M10 flush end terminals and microswitch adapter
909.634.43
| Series name | B500 | Power loss (W) | 205 |
| Rated current In (A) | 750 | Class | aBat |
| Fuse Dimension (mm) | 103x144 | Rated Voltage Un DC (V) | 1500 |
| Rated breaking capacity I1 DC (kA) | 250 | Fuse Connection/Terminal type | Screw fixing |
| Melting I²t value (A²s) | 228000 | Fixing dimensions | M10 |
| Total clearing I²t @Un DC (A²s) | 1264000 | Minimum breaking current (A) | 8700 |
| Applicable standards | IEC |
