Fuse 1000VDC gPV 12A 10x38mm
799.317.97
| Series name | V103 | Power loss (W) | 2,50 |
| Rated current In (A) | 12 | Class | gPV |
| Fuse Dimension (mm) | 10x38 | Rated Voltage Un DC (V) | 1000 |
| Rated breaking capacity I1 DC (kA) | 20 | Time costant L/R (ms) | ≤3 |
| Fuse Connection/Terminal type | Cylindrical | Melting I²t value (A²s) | 12,5 |
| Total clearing I²t @Un DC (A²s) | 113 | Applicable standards | IEC |
