Fuse 690VAC aR 1000A size 3 76x50mm M12 flush end terminals
998.554.76
| Series name | C300 | Power loss (W) | 132 |
| Rated current In (A) | 1000 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 200 |
| Fuse size | 3 | Fuse Connection/Terminal type | Screw fixing |
| Melting I²t value (A²s) | 140000 | Fixing dimensions | M12 |
| Total clearing I²t @Un AC (A²s) | 840000 | Applicable standards | IEC |
