Fuse 690VAC aR 125A size 1 53x50,5mm M8 flush end terminals, with microswitch adapter
537.101.78
| Series name | C100 | Power loss (W) | 30 |
| Rated current In (A) | 125 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 200 |
| Fuse Dimension (mm) | 53x50,5 | Fuse size | 1 |
| Fuse Connection/Terminal type | Screw fixing | Melting I²t value (A²s) | 650 |
| Fixing dimensions | M8 | Total clearing I²t @Un AC (A²s) | 3580 |
| Applicable standards | IEC |
