Fuse 690VAC aR 550A size 1 53x52mm M8 flush end terminals
114.997.24
| Series name | C100 | Power loss (W) | 84 |
| Rated current In (A) | 550 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 100 |
| Fuse Dimension (mm) | 53x52 | Fuse Connection/Terminal type | Screw fixing |
| Melting I²t value (A²s) | 33000 | Fixing dimensions | M8 |
| Total clearing I²t @Un AC (A²s) | 230000 | Applicable standards | IEC |
