Fuse 690VAC aR 630A size 2 61x50mm M10 flush end terminals
111.779.56
| Series name | C200 | Power loss (W) | 84 |
| Rated current In (A) | 630 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 200 |
| Fuse Dimension (mm) | 61x50 | Fuse size | 2 |
| Fuse Connection/Terminal type | Screw fixing | Melting I²t value (A²s) | 55500 |
| Fixing dimensions | M10 | Total clearing I²t @Un AC (A²s) | 305000 |
| Applicable standards | IEC |
