Fuse 690VAC/700VDC aR 315A DIN00/80 with indicator and with lug for microswitch fitting - fixing centres 80mm
712.042.86
| Series name | NR2B | Power loss (W) | 70 |
| Rated current In (A) | 315 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 200 |
| Rated Voltage Un DC (V) | 700 | Fuse size | NH00 |
| Rated breaking capacity I1 DC (kA) | 30 | Fixing connection centres (mm) | 80 |
| Time costant L/R (ms) | 2 | Fuse Connection/Terminal type | Screw fixing |
| Melting I²t value (A²s) | 16450 | Total clearing I²t @Un AC (A²s) | 60000 |
| Total clearing I²t @Un DC (A²s) | 71600 | Applicable standards | IEC |
