List of products by manufacturer FAULTRAP

Showing 361-384 of 839 item(s)

Fuse 1500VDC gPV 25A 10x85mm

Reference: 984.545.26

Series name: V108

Power loss (W): 5,59

Rated current In (A): 25

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 175,22

Total clearing I²t @Un DC (A²s): 827

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 25A 10x85mm in-line terminals

Reference: 965.085.72

Series name: V108

Power loss (W): 5,59

Rated current In (A): 25

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 175,22

Total clearing I²t @Un DC (A²s): 827

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 2A 10x85mm

Reference: 322.946.60

Series name: V108

Power loss (W): 1,66

Rated current In (A): 2

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 4,15

Total clearing I²t @Un DC (A²s): 10

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 2A 10x85mm in-line terminals

Reference: 781.529.66

Series name: V108

Power loss (W): 1,66

Rated current In (A): 2

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 4,15

Total clearing I²t @Un DC (A²s): 10

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 30A 10x85mm

Reference: 232.383.85

Series name: V108

Power loss (W): 7,12

Rated current In (A): 30

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 265,42

Total clearing I²t @Un DC (A²s): 980

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 30A 10x85mm in-line terminals

Reference: 451.945.62

Series name: V108

Power loss (W): 7,12

Rated current In (A): 30

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 265,42

Total clearing I²t @Un DC (A²s): 980

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 32A 10x85mm

Reference: 210.825.49

Series name: V108

Power loss (W): 7,72

Rated current In (A): 32

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 299,64

Total clearing I²t @Un DC (A²s): 4286

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 32A 10x85mm in-line terminals

Reference: 501.152.94

Series name: V108

Power loss (W): 7,72

Rated current In (A): 32

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 299,64

Total clearing I²t @Un DC (A²s): 4286

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 32A 22x65mm

Reference: 845.638.80

Series name: VP22

Power loss (W): 6,3

Rated current In (A): 32

Class: gPV, gR

Rated Voltage Un AC (V): 800

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 22x65

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 10

Time costant L/R (ms): 1-3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 190

Total clearing I²t @Un AC (A²s): 1100

Total clearing I²t @Un DC (A²s): 1650

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 35A 22x65mm

Reference: 794.621.04

Series name: VP22

Power loss (W): 6,5

Rated current In (A): 35

Class: gPV, gR

Rated Voltage Un AC (V): 800

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 22x65

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 10

Time costant L/R (ms): 1-3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 270

Total clearing I²t @Un AC (A²s): 15000

Total clearing I²t @Un DC (A²s): 2300

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 3A 10x85mm

Reference: 785.688.75

Series name: V108

Power loss (W): 1,89

Rated current In (A): 3

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Melting I²t value (A²s): 5,25

Total clearing I²t @Un DC (A²s): 12

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 3A 10x85mm in-line terminals

Reference: 105.250.53

Series name: V108

Power loss (W): 1,89

Rated current In (A): 3

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 5,25

Total clearing I²t @Un DC (A²s): 12

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 40A 22x65mm

Reference: 360.932.23

Series name: VP22

Power loss (W): 7

Rated current In (A): 40

Class: gPV, gR

Rated Voltage Un AC (V): 800

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 22x65

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 10

Time costant L/R (ms): 1-3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 420

Total clearing I²t @Un AC (A²s): 2350

Total clearing I²t @Un DC (A²s): 3650

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 4A 10x85mm

Reference: 902.355.78

Series name: V108

Power loss (W): 2,16

Rated current In (A): 4

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 6,48

Total clearing I²t @Un DC (A²s): 23

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 4A 10x85mm in-line terminals

Reference: 770.725.83

Series name: V108

Power loss (W): 2,16

Rated current In (A): 4

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 6,48

Total clearing I²t @Un DC (A²s): 23

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 50A 22x65mm

Reference: 635.145.22

Series name: VP22

Power loss (W): 9

Rated current In (A): 50

Class: gPV, gR

Rated Voltage Un AC (V): 800

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 22x65

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 10

Time costant L/R (ms): 1-3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 740

Total clearing I²t @Un AC (A²s): 4100

Total clearing I²t @Un DC (A²s): 6550

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 5A 10x85mm

Reference: 481.589.02

Series name: V108

Power loss (W): 2,48

Rated current In (A): 5

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 7,84

Total clearing I²t @Un DC (A²s): 33,8

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 5A 10x85mm in-line terminals

Reference: 603.660.85

Series name: V108

Power loss (W): 2,48

Rated current In (A): 5

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 7,84

Total clearing I²t @Un DC (A²s): 33,8

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 6A 10x85mm

Reference: 982.783.96

Series name: V108

Power loss (W): 2,50

Rated current In (A): 6

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 9,33

Total clearing I²t @Un DC (A²s): 38

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 6A 10x85mm in-line terminals

Reference: 865.834.50

Series name: V108

Power loss (W): 2,50

Rated current In (A): 6

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 9,33

Total clearing I²t @Un DC (A²s): 38

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 8A 10x85mm

Reference: 984.092.61

Series name: V108

Power loss (W): 2,72

Rated current In (A): 8

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 10,95

Total clearing I²t @Un DC (A²s): 48,5

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1500VDC gPV 8A 10x85mm in-line terminals

Reference: 740.292.26

Series name: V108

Power loss (W): 2,72

Rated current In (A): 8

Class: gPV

Fuse Dimension (mm): 10x85

Rated Voltage Un DC (V): 1500

Rated breaking capacity I1 DC (kA): 20

Time costant L/R (ms): ≤3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 10,95

Total clearing I²t @Un DC (A²s): 48,5

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 150V AC aR 2800A size 3 with plate and microswitch...

Reference: 729.032.67

Series name: C315P

Power loss (W): 150

Rated current In (A): 2800

Class: aR

Rated Voltage Un AC (V): 150

Rated breaking capacity I1 AC (kA): 230

Fuse size: 3

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 1845000

Fixing dimensions: M12

Total clearing I²t @Un AC (A²s): 5535000

Applicable standards: IEC

Available

Datasheet

Compare

Fuse 2000V DC 35A 22x85mm gPV in-line alluminum 4AWG

Reference: 433.371.43

Series name: 20PV22

Power loss (W): 10,7

Rated current In (A): 35

Class: gPV

Fuse Dimension (mm): 22x85

Rated Voltage Un DC (V): 2000

Rated breaking capacity I1 DC (kA): 50

Time costant L/R (ms): 1-3

Fuse Connection/Terminal type: In-line for aluminum cable

Melting I²t value (A²s): 265

Applicable standards: IEC

Available

3D Datasheet

Compare

839 items
