Fuse 1500VDC gPV 25A 22x65mm
568.895.42
| Series name | PV22 | Power loss (W) | 6,5 |
| Rated current In (A) | 25 | Class | gPV |
| Fuse Dimension (mm) | 22x65 | Rated Voltage Un DC (V) | 1500 |
| Rated breaking capacity I1 DC (kA) | 10 | Time costant L/R (ms) | 1-3 |
| Fuse Connection/Terminal type | Cylindrical | Melting I²t value (A²s) | 130 |
| Total clearing I²t @Un DC (A²s) | 1400 | Applicable standards | IEC |
