Fuse 1500VDC gPV 75A 22x65mm
554.542.31
| Series name | PV22 | Power loss (W) | 13,5 |
| Rated current In (A) | 75 | Class | gPV |
| Fuse Dimension (mm) | 22x65 | Rated Voltage Un DC (V) | 1500 |
| Rated breaking capacity I1 DC (kA) | 10 | Time costant L/R (ms) | 1-3 |
| Fuse Connection/Terminal type | Cylindrical | Melting I²t value (A²s) | 2480 |
| Total clearing I²t @Un DC (A²s) | 12500 | Applicable standards | UL |
