Fuse 690VAC aR 1000A size 3 76x52,4mm M12 flush end terminals
142.447.72
| Series name | C300 | Power loss (W) | 140 |
| Rated current In (A) | 1000 | Class | aR |
| Rated Voltage Un AC (V) | 690 | Rated breaking capacity I1 AC (kA) | 200 |
| Fuse Dimension (mm) | 76x52,4 | Fuse size | 3 |
| Fuse Connection/Terminal type | Screw fixing | Melting I²t value (A²s) | 140000 |
| Fixing dimensions | M12 | Total clearing I²t @Un AC (A²s) | 840000 |
| Applicable standards | IEC |
