All Products

Showing 37-48 of 807 item(s)

Fuse 690VAC aR 400A DIN00/80 with indicator and with lug...

Reference: 152.430.74

Series name: NR2B

Rated current In (A): 400

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 200

Rated Voltage Un DC (V): 700

Fuse size: NH00

Rated breaking capacity I1 DC (kA): 30

Time costant L/R (ms): 2

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse BS 240VAC/150VDC aR 10A 17x56mm fixing centres 42mm

Reference: 154.059.27

Series name: 24E1

Power loss (W): 2,3

Rated current In (A): 10

Class: aR

Rated Voltage Un AC (V): 240

Rated breaking capacity I1 AC (kA): 100

Rated Voltage Un DC (V): 150

Rated breaking capacity I1 DC (kA): 20

Melting I²t value (A²s): 3,5

Total clearing I²t @Un AC (A²s): 17,6

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 500VAC IEC/550VAC UL aR 12A 22x58mm surface mount,...

Reference: 157.322.07

Series name: UR22

Power loss (W): 3,5

Rated current In (A): 12

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 200

Fuse Dimension (mm): 22x58

Fixing connection centres (mm): 80

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 8,5

Total clearing I²t @Un AC (A²s): 37

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 690VAC aR 10A 14x51mm

Reference: 157.396.21

Series name: A145

Power loss (W): 2,8

Rated current In (A): 10

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 200

Fuse Dimension (mm): 14x51

Fuse Connection/Terminal type: Cylindrical

Melting I²t value (A²s): 8

Total clearing I²t @Un AC (A²s): 40

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 1000VDC aBat/aR 750A 63x167mm silver plated axial...

Reference: 157.565.30

Series name: B100

Power loss (W): 140

Rated current In (A): 750

Class: aBat

Fuse Dimension (mm): 63x167

Rated Voltage Un DC (V): 1000

Rated breaking capacity I1 DC (kA): 100

Fixing connection centres (mm): 132,75

Time costant L/R (ms): 2

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 166000

Total clearing I²t @Un DC (A²s): 500000

Minimum breaking current (A): 7500

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1000VDC aBat/aR 125A 38x129mm silver plated axial...

Reference: 157.806.86

Series name: B025

Power loss (W): 19

Rated current In (A): 125

Class: aBat, aR

Fuse Dimension (mm): 38x129

Rated Voltage Un DC (V): 1000

Rated breaking capacity I1 DC (kA): 100

Time costant L/R (ms): 2

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 3500

Total clearing I²t @Un DC (A²s): 8000

Minimum breaking current (A): 1000

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1000VDC aBat/aR 250A 50x129mm silver plated axial...

Reference: 160.833.51

Series name: B050

Power loss (W): 36

Rated current In (A): 250

Class: aBat, aR

Fuse Dimension (mm): 50x129

Rated Voltage Un DC (V): 1000

Rated breaking capacity I1 DC (kA): 100

Time costant L/R (ms): 2

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 15000

Total clearing I²t @Un DC (A²s): 40000

Minimum breaking current (A): 2500

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 1000VDC aBat/aR 800A 63x203mm tin plated axial...

Reference: 161.186.65

Series name: B100

Power loss (W): 150

Rated current In (A): 800

Class: aBat

Fuse Dimension (mm): 63x203

Rated Voltage Un DC (V): 1000

Rated breaking capacity I1 DC (kA): 100

Fixing connection centres (mm): 152,7

Time costant L/R (ms): 2

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 185000

Total clearing I²t @Un DC (A²s): 550000

Minimum breaking current (A): 8000

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 2000VDC gPV 80A 27x85mm in-line terminal for copper...

Reference: 166.238.86

Series name: 20PV27

Power loss (W): 20

Rated current In (A): 80

Class: gPV

Fuse Dimension (mm): 27x85

Rated Voltage Un DC (V): 2000

Rated breaking capacity I1 DC (kA): 50

Time costant L/R (ms): 1-3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 2400

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 1000VDC aBat/aR 750A 63x106mm 2x M12 flush end...

Reference: 168.384.52

Series name: B100

Power loss (W): 140

Rated current In (A): 750

Class: aBat

Fuse Dimension (mm): 63x106

Rated Voltage Un DC (V): 1000

Rated breaking capacity I1 DC (kA): 100

Time costant L/R (ms): 2

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 166000

Fixing dimensions: M12

Total clearing I²t @Un DC (A²s): 500000

Minimum breaking current (A): 7500

Applicable standards: IEC, UL

Available

3D Datasheet

Compare

Fuse 2000VDC gPV 12A 14x85mm in-line terminals

Reference: 170.071.20

Series name: 20PV14

Power loss (W): 4

Rated current In (A): 12

Class: gPV

Fuse Dimension (mm): 14x85

Rated Voltage Un DC (V): 2000

Rated breaking capacity I1 DC (kA): 50

Time costant L/R (ms): 1-3

Fuse Connection/Terminal type: In-line for copper cable

Melting I²t value (A²s): 23

Applicable standards: IEC

Available

3D Datasheet

Compare

Fuse 690VAC aR 50A size 1 53x52mm M8 flush end terminals

Reference: 171.033.15

Series name: C100

Power loss (W): 8

Rated current In (A): 50

Class: aR

Rated Voltage Un AC (V): 690

Rated breaking capacity I1 AC (kA): 100

Fuse Dimension (mm): 53x52

Fuse Connection/Terminal type: Screw fixing

Melting I²t value (A²s): 77

Fixing dimensions: M8

Total clearing I²t @Un AC (A²s): 510

Applicable standards: IEC

Available

3D Datasheet

Compare

807 items
