Fuse 2000VDC aBat 700A 76x218mm Double body Flush-End Terminals M12
669.293.11
| Series name | 20BP3 | Power loss (W) | 220 |
| Rated current In (A) | 700 | Class | aBat |
| Fuse Dimension (mm) | 76x218 | Rated Voltage Un DC (V) | 2000 |
| Rated breaking capacity I1 DC (kA) | 50 | Time costant L/R (ms) | 1-3 |
| Fuse Connection/Terminal type | Screw fixing | Fixing dimensions | M12 |
| Minimum breaking current (A) | 7000 | Applicable standards | IEC |
